28mm Hybrid NEMA 11 Stepper Motor Micro Stepping Motor For Robot Camera

28mm Hybrid NEMA 11 Stepper Motor Micro Stepping Motor For Robot Camera

ব্র্যান্ড নাম:	Casun
মডেল নম্বর:	28SHD4401-20B1
MOQ:	1 পিসি
দাম:	$5.94-$8.6
পেমেন্ট শর্তাবলী:	D/A, T/T, L/C, D/P
সরবরাহ ক্ষমতা:	40000+Pcs+মাস

বিস্তারিত তথ্য

পণ্য বিবরণ

বিস্তারিত তথ্য

উৎপত্তি স্থল:

চীন

সাক্ষ্যদান:

CE,ROSH,ISO

স্টেপ এঞ্জেল:

1.8°

টর্ক ধরে রাখা:

95mN.m

কারেন্ট:

0.67A

মোটর দৈর্ঘ্য:

44 মিমি

খাদ:

মিলিং ফ্ল্যাট খাদ 20 মিমি দৈর্ঘ্য

কাস্টমাইজড:

মোটরটি কাস্টমাইজড অনুরোধের সাথে ডিজাইন এবং তৈরি করা যেতে পারে।

প্যাকেজিং বিবরণ:

শক্ত কাগজ: 36x29x14 সেমি

বিশেষভাবে তুলে ধরা:

28mm Hybrid NEMA 11 Stepper Motor

NEMA 11 Micro Stepping Motor

28mm NEMA 11 Stepper Motor

পণ্য বিবরণ

The 28mm Hybrid Stepper Motor Series offers powerful holding torque in a variety of sizes.

Medical and scientific equipment, as well as household appliances, 3D printers, image scanners, and car navigation.

Features:

Each model of stepper motor can be suitable for different scenarios
Needed dealers! !
Available in single or double shaft versions
CE and RoHS approved
Within 48 hours, one of our engineers will contact you with the best option

Motor Specifications

Step Angel	1.8 °
Fram Size	28 mm
Number of Phase	2 Phase
Rated Current	0.67 A
Holding Torque	95 mN.m
Resistance	6.8 ohm
Inductance	5 mH
Rotor Inertia	9 g-cm²
Motor weight	0.12 kg
Number of leads	4
Connection	Bipolar

Appearance

Dimensions

Torque Curves

Download

If our standard motor cannot meet your needs,

we can customize the motor according to your needs

Customized content includes but is not limited to special shafts, winding parameters, installation dimensions, lead wires with special requirements, connectors, etc.

Options:
Encoder | Brake | Gearbox | Connector

Please click the "Get a quote" button below to tell us your requirements.
