35x35mm 155mN.M Nema 14 Hybrid Stepper Motor For Beauty Equipment 1A 3.8V

35x35mm 155mN.M Nema 14 Hybrid Stepper Motor For Beauty Equipment 1A 3.8V

ব্র্যান্ড নাম:	Casun
মডেল নম্বর:	35SHD4103-10B
MOQ:	1 পিসি
দাম:	$4.2-$5.2
পেমেন্ট শর্তাবলী:	D/A, T/T, L/C, D/P
সরবরাহ ক্ষমতা:	40000+Pcs+মাস

বিস্তারিত তথ্য

পণ্য বিবরণ

বিস্তারিত তথ্য

উৎপত্তি স্থল:

চীন

সাক্ষ্যদান:

CE,ROSH,ISO

স্টেপ এঞ্জেল:

1.8°

টর্ক ধরে রাখা:

155mN.m

কারেন্ট:

মোটর দৈর্ঘ্য:

34 মিমি

খাদ:

বৃত্তাকার খাদ 10 মিমি দৈর্ঘ্য

কাস্টমাইজড:

মোটরটি কাস্টমাইজড অনুরোধের সাথে ডিজাইন এবং তৈরি করা যেতে পারে।

প্যাকেজিং বিবরণ:

শক্ত কাগজ: 36x29x14 সেমি

বিশেষভাবে তুলে ধরা:

35x35mm 155mN.M Nema 14

Nema 14 Hybrid Stepper Motor

1A 3.8V Nema 14 Stepper Motor

পণ্য বিবরণ

Nema 14 Hybrid stepper motor 35x35mm 1A 3.8V 155mN.m for beauty equipment

20x20x33mm 0.6A Casun Stepper Motor Nema 8 Mini Stepper Motor For Medical beauty equipment

Motor Specifications

Step Angel	1.8 °
Fram Size	35 mm
Number of Phase	2 Phase
Rated Current	1 A
Holding Torque	155 mN.m
Resistance	3.8 ohm
Inductance	5.8mH
Rotor Inertia	14 g-cm²
Motor weight	0.18 kg
Number of leads	4
Connection	Bipolar

Appearance

Dimensions

Torque Curves

Download

If our standard motor cannot meet your needs,

we can customize the motor according to your needs

Customized content includes but is not limited to special shafts, winding parameters, installation dimensions, lead wires with special requirements, connectors, etc.

Options:
Encoder | Brake | Gearbox | Connector

Please click the "Get a quote" button below to tell us your requirements.
