1.8 Degree Hollow Shaft NEMA 11 Micro Stepper Motor For Medical Machine Robot Camera

1.8 Degree Hollow Shaft NEMA 11 Micro Stepper Motor For Medical Machine Robot Camera

ব্র্যান্ড নাম:	Casun
মডেল নম্বর:	28SHD4501-K1
MOQ:	1 পিসি
দাম:	$4.14-$6.98
পেমেন্ট শর্তাবলী:	D/A, T/T, L/C, D/P
সরবরাহ ক্ষমতা:	40000+Pcs+মাস

বিস্তারিত তথ্য

পণ্য বিবরণ

বিস্তারিত তথ্য

উৎপত্তি স্থল:

চীন

সাক্ষ্যদান:

CE,ROHS,ISO

স্টেপ এঞ্জেল:

1.8°

টর্ক ধরে রাখা:

120mN.m

কারেন্ট:

0.67A

মোটর দৈর্ঘ্য:

51.5 মিমি

খাদ:

ফাঁকা

কাস্টমাইজড:

মোটরটি কাস্টমাইজড অনুরোধের সাথে ডিজাইন এবং তৈরি করা যেতে পারে।

প্যাকেজিং বিবরণ:

শক্ত কাগজ: 36x29x14 সেমি

বিশেষভাবে তুলে ধরা:

2 Phase Micro Stepper Motor

1.8 Degree Micro Stepper Motor

NEMA 11 Micro Stepper Motor

পণ্য বিবরণ

2 Phase 1.8 Degree Hollow Shaft NEMA 11 Micro Stepper Motor for Medical Machine Robot Camera

The 28mm Hybrid Stepper Motor Series offers powerful holding torque in a variety of sizes.

Use with a microstepping driver to reduce vibration and achieve higher step resolution.

Choose a baseline version or request your own customized configuration.

Features:

Professional drivetrain solution specialist
Hybrid stepper construction
Available in single or double shaft versions
Professional research and development manufacturing
Customizations on request

Appearance

Dimensions

Motor Specifications

Step Angel	1.8 °
Fram Size	28 mm
Number of Phase	2 Phase
Rated Current	0.67 A
Holding Torque	120 mN.m
Resistance	9.5 ohm
Inductance	6.8 mH
Rotor Inertia	18 g-cm²
Motor weight	0.2 kg
Number of leads	4
Connection	Bipolar

Torque Curves

Download

If our standard motor cannot meet your needs,

we can customize the motor according to your needs

Customized content includes but is not limited to special shafts, winding parameters, installation dimensions, lead wires with special requirements, connectors, etc.

Options:
Encoder | Brake | Gearbox | Connector

Please click the "Get a quote" button below to tell us your requirements.
