1.8 Degree 2 Phase Stepper Motor For Engraving Machinery 17.5N.M Hybrid NEMA 23

1.8 Degree 2 Phase Stepper Motor For Engraving Machinery 17.5N.M Hybrid NEMA 23

ব্র্যান্ড নাম:	Casun
মডেল নম্বর:	57SHD0805-26BH
MOQ:	1 পিসি
দাম:	$3.14-$5
পেমেন্ট শর্তাবলী:	D/A, T/T, L/C, D/P
সরবরাহ ক্ষমতা:	40000+Pcs+মাস

বিস্তারিত তথ্য

পণ্য বিবরণ

বিস্তারিত তথ্য

উৎপত্তি স্থল:

চীন

সাক্ষ্যদান:

CE,ROHS,ISO

স্টেপ এঞ্জেল:

1.8°

টর্ক ধরে রাখা:

1750mN.m

কারেন্ট:

2.5 এ

মোটর দৈর্ঘ্য:

76 মিমি

খাদ:

মিলিং ফ্ল্যাট খাদ 26 মিমি দৈর্ঘ্য

কাস্টমাইজড:

মোটরটি কাস্টমাইজড অনুরোধের সাথে ডিজাইন এবং তৈরি করা যেতে পারে।

প্যাকেজিং বিবরণ:

শক্ত কাগজ: 36x29x14 সেমি

বিশেষভাবে তুলে ধরা:

1.8 Degree 2 Phase Stepper Motor

Hybrid 2 Phase Stepper Motor

পণ্য বিবরণ

1.8 Degree 2 Phase Stepper Motor Suitable for Engraving Machinery 17.5N.m Hybrid NEMA 23

NEMA 23 stepper motors are usually made of high-quality materials, which have good durability and long lifespan.

Applied to CNC machine tools, 3D printers, and automation equipment.

Features:

High torque and high precision
For high-tech industry and electronic industry equipment
Dealers are actively sought after!
We are open to contract manufacturing arrangements
Ten-year warranty and purchase with confidence

Appearance

1.8 Degree 2 Phase Stepper Motor For Engraving Machinery 17.5N.M Hybrid NEMA 23 0

Dimensions

1.8 Degree 2 Phase Stepper Motor For Engraving Machinery 17.5N.M Hybrid NEMA 23 1

Motor Specifications

Step Angel	1.8 °
Fram Size	57 mm
Number of Phase	2 Phase
Rated Current	2.5 A
Holding Torque	1750 mN.m
Resistance	2.4 ohm
Inductance	9.0 mH
Rotor Inertia	460 g-cm²
Motor weight	1 kg
Number of leads	4
Connection	Bipolar

Operating Specifications

Step Angle: 1.8°

Maximum Temperature :80°C maximum

Ambient Temperature: -20 °C to 50°C

Storage Temperature -20: °C to 100°C

Humidity Range (%) :85% or less, non-condensing

Magnet Wire Insulation :Class B 130 deg C

Insulation Resistance :100M Ohm at 500 VDC

Dielectric Strength :500 VDC for 1 min

Torque Curves

Submodels

Model	Holding Torque	Step Angle	Length	Type of Shaft	Rated Current
57SHD4013-21B	0.6N.m	1.8°	41mm	D Shaft-21mm	1.0A
57SHD4415-21B	1.1N.m	1.8°	54mm	D Shaft-21mm	3.0A
57SHD4816-21B	2.0N.m	1.8°	76mm	D Shaft-21mm	3.0A
57SHD4913-21B	2.5N.m	1.8°	83mm	D Shaft-21mm	3.0A
57SHD4934-20B	3.0N.m	1.8°	100mm	D Shaft-20mm	3.0A

Download

If our standard motor cannot meet your needs,

we can customize the motor according to your needs

Customized content includes but is not limited to special shafts, winding parameters, installation dimensions, lead wires with special requirements, connectors, etc.

Options:

Encoder	Brake	Gearbox	Shaft

Please click the "Get a quote" button below to tell us your requirements.
