Micro NEMA 11 Stepper Motor 0.67A 2 Phase Wiring For Revolving Light

Micro NEMA 11 Stepper Motor 0.67A 2 Phase Wiring For Revolving Light

ব্র্যান্ড নাম:	Casun
মডেল নম্বর:	28SHD4401-20B
MOQ:	1 পিসি
দাম:	$6.49-$9.5
পেমেন্ট শর্তাবলী:	D/A, T/T, L/C, D/P
সরবরাহ ক্ষমতা:	40000+Pcs+মাস

বিস্তারিত তথ্য

পণ্য বিবরণ

বিস্তারিত তথ্য

উৎপত্তি স্থল:

চীন

সাক্ষ্যদান:

CE,ROSH,ISO

স্টেপ এঞ্জেল:

1.8°

টর্ক ধরে রাখা:

95mN.m

কারেন্ট:

0.67A

মোটর দৈর্ঘ্য:

44.6 মিমি

খাদ:

ডি খাদ 20 মিমি দৈর্ঘ্য

রঙ:

সিলভার

ভোল্টেজ:

5.56V

কাস্টমাইজড:

মোটরটি কাস্টমাইজড অনুরোধের সাথে ডিজাইন এবং তৈরি করা যেতে পারে।

প্যাকেজিং বিবরণ:

শক্ত কাগজ: 36x29x14 সেমি

বিশেষভাবে তুলে ধরা:

Micro NEMA 11 Stepper Motor

2 Phase NEMA 11 Stepper Motor

পণ্য বিবরণ

Hot Sale Micro NEMA 11 Stepper Motor 0.67A Stepping Motors 2 Phase Wiring For Revolving Light

28*28*44mm 0.67A 4.56V 2 Phase Wiring 1.8 Degree Stepper Motor Nema 11 Micro Stepping Motor

The 28mm Hybrid Stepper Motor Series offers powerful holding torque in a variety of sizes.

Use with a microstepping driver to reduce vibration and achieve higher step resolution.

Choose a baseline version or request your own customized configuration.

Features:

Bipolar or unipolar versions available
Hybrid stepper construction
Available in single or double shaft versions
CE and RoHS approved
Customizations on request

Appearance

Dimensions

Motor Specifications

Step Angel	1.8 °
Fram Size	28 mm
Number of Phase	2 Phase
Rated Current	0.6 7A
Holding Torque	95 mN.m
Resistance	6.8 ohm
Inductance	4.9 mH
Rotor Inertia	9 g-cm²
Motor weight	0.16 kg
Number of leads	4
Connection	Bipolar

Torque Curves

Micro NEMA 11 Stepper Motor 0.67A 2 Phase Wiring For Revolving Light 2

Download

If our standard motor cannot meet your needs,

we can customize the motor according to your needs

Customized content includes but is not limited to special shafts, winding parameters, installation dimensions, lead wires with special requirements, connectors, etc.

Options:
Encoder | Brake | Gearbox | Connector

Please click the "Get a quote" button below to tell us your requirements.
