NEMA 14 Hollow Stepper Motor Dual Shaft 1.0A 0.19N.M For Image Scanners

NEMA 14 Hollow Stepper Motor Dual Shaft 1.0A 0.19N.M For Image Scanners

ব্র্যান্ড নাম:	Casun
মডেল নম্বর:	P35SHD4150-9SKH
MOQ:	1 পিসি
দাম:	$4.14-$6.98
পেমেন্ট শর্তাবলী:	D/A, T/T, L/C, D/P
সরবরাহ ক্ষমতা:	40000+Pcs+মাস

বিস্তারিত তথ্য

পণ্য বিবরণ

বিস্তারিত তথ্য

উৎপত্তি স্থল:

চীন

সাক্ষ্যদান:

CE,ROHS,ISO

স্টেপ এঞ্জেল:

1.8°

টর্ক ধরে রাখা:

190mN.m

কারেন্ট:

1.0A

মোটর দৈর্ঘ্য:

34 মিমি

খাদ:

ডাবল ফাঁপা 9 মিমি দৈর্ঘ্য

কাস্টমাইজড:

মোটরটি কাস্টমাইজড অনুরোধের সাথে ডিজাইন এবং তৈরি করা যেতে পারে।

প্যাকেজিং বিবরণ:

শক্ত কাগজ: 36x29x14 সেমি

বিশেষভাবে তুলে ধরা:

NEMA 14 Hollow Stepper Motor

Dual Shaft Hollow Stepper Motor

পণ্য বিবরণ

NEMA 14 Hollow Stepper Motor Dual Shaft 1.0A 0.19N.M For Image Scanners

The central part of the rotor is designed to be hollow and can transmit signals such as gas, liquid, or optical fibers through axial through-holes.

Consisting of two independent rotors, each rotor can be independently controlled.

Features:

Our engineers will reach out within 48 hours to offer the optimal solution
A ten-year warranty for confident purchases
Available in variations with a single or double shaft
Expert manufacturing research and development
Our engineers will respond within 48 hours to provide the best solution

Motor Specifications

Step Angel	1.8 °
Fram Size	35 mm
Number of Phase	2 Phase
Rated Current	1.0 A
Holding Torque	190 mN.m
Resistance	3.5 ohm
Inductance	3.6 mH
Rotor Inertia	20 g-cm²
Motor weight	0.18 kg
Number of leads	4
Connection	Bipolar

Appearance

Dimensions

Torque Curves

Download

If our standard motor cannot meet your needs,

we can customize the motor according to your needs

Customized content includes but is not limited to special shafts, winding parameters, installation dimensions, lead wires with special requirements, connectors, etc.

Options:
Encoder | Brake | Gearbox | Connector

Please click the "Get a quote" button below to tell us your requirements.
