High Accuracy 1.8 Degree 282845mm Nema 11 Hybrid Stepper Motor 1.5A for ATM Machine

High Accuracy 1.8 Degree 282845mm Nema 11 Hybrid Stepper Motor 1.5A for ATM Machine

ব্র্যান্ড নাম:	Casun
মডেল নম্বর:	28SHD0405-15B
MOQ:	1 পিসি
দাম:	$6.89-$14
পেমেন্ট শর্তাবলী:	D/A, T/T, L/C, D/P
সরবরাহ ক্ষমতা:	40000+Pcs+মাস

বিস্তারিত তথ্য

পণ্য বিবরণ

বিস্তারিত তথ্য

উৎপত্তি স্থল:

চীন

সাক্ষ্যদান:

CE,ROHS,ISO

স্টেপ এঞ্জেল:

1.8°

টর্ক ধরে রাখা:

120mN.m

কারেন্ট:

1.5a

মোটর দৈর্ঘ্য:

45 মিমি

খাদ:

মিলিং ফ্ল্যাট খাদ 10 মিমি দৈর্ঘ্য

কাস্টমাইজড:

মোটরটি কাস্টমাইজড অনুরোধের সাথে ডিজাইন এবং তৈরি করা যেতে পারে।

প্যাকেজিং বিবরণ:

শক্ত কাগজ: 36x29x14 সেমি

বিশেষভাবে তুলে ধরা:

1.5A Nema 11 Hybrid Stepper Motor

282845mm Nema 11 Hybrid Stepper Motor

পণ্য বিবরণ

It has a wide range of application advantages in the fields of automation control and precision positioning.

3D printers, small robots, medical equipment, automatic testing equipment, etc.

Features:

Versions in unipolar or bipolar are offered
Hybrid stepper building
Production with knowledge of research and development
With 12 years of establishment in China and a clientele exceeding 800
Offering a ten-year warranty for confident purchasing

Motor Specifications

Step Angel	1.8 °
Fram Size	28 mm
Number of Phase	2 Phase
Rated Current	1.5 A
Holding Torque	120 mN.m
Resistance	2.7 ohm
Inductance	1.9 mH
Rotor Inertia	9 g-cm²
Motor weight	0.16 kg
Number of leads	4
Connection	Bipolar

Dimensions

Torque Curves

Download

If our standard motor cannot meet your needs,

we can customize the motor according to your needs

Customized content includes but is not limited to special shafts, winding parameters, installation dimensions, lead wires with special requirements, connectors, etc.

FAQ

1. who are we?

We are based in Guangdong, China, start from 2011,sell to Domestic Market(63.00%),Western Europe(12.00%),North America(9.00%),Eastern Asia(8.00%),Northern Europe(2.00%),Eastern Europe(00.00%),Southeast Asia(00.00%),Oceania(00.00%),Mid East(00.00%),Southern Europe(00.00%),South Asia(00.00%). There are total about 51-100 people in our office.

2. how can we guarantee quality?

Always a pre-production sample before mass production;

Always final Inspection before shipment;

3.what can you buy from us?

Stepper Motor,BLDC Motor

4. why should you buy from us not from other suppliers?

We are specialized in producing and selling stepper motors for more than 11 years.

5. what services can we provide?

Accepted Delivery Terms: FOB,CFR,CIF,EXW,Express Delivery；

Accepted Payment Currency:USD,CNY;

Accepted Payment Type: T/T,L/C,D/P D/A,,PayPal;

Language Spoken:English,Chinese,Japanese

Options:
Encoder | Brake | Gearbox | Connector

Please click the "Get a quote" button below to tell us your requirements.
