পণ্যের বিবরণ

Created with Pixso. বাড়ি Created with Pixso. পণ্য Created with Pixso.
Close Loop Stepper Motor
Created with Pixso.

NEMA 23 Hollow Shaft Stepper Motor 57x57x54mm For Bespoke Ball Screw Or Lead Screw

নাম

NEMA 23 Hollow Shaft Stepper Motor 57x57x54mm For Bespoke Ball Screw Or Lead Screw

ব্র্যান্ড নাম: Casun
মডেল নম্বর: 57SHB4406-20BQH
MOQ: 1 পিসি
দাম: $3.14-$5
পেমেন্ট শর্তাবলী: D/A, T/T, L/C, D/P
সরবরাহ ক্ষমতা: 40000+Pcs+মাস
বিস্তারিত তথ্য
পণ্য বিবরণ
বিস্তারিত তথ্য
উৎপত্তি স্থল:
চীন
সাক্ষ্যদান:
CE,ROHS,ISO
স্টেপ এঞ্জেল:
1.8°
রেট দেওয়া খোঁচা:
৮০০ এন
কারেন্ট:
2.২এ
মোটর দৈর্ঘ্য:
54 মিমি
কাস্টমাইজড:
মোটরটি কাস্টমাইজড অনুরোধের সাথে ডিজাইন এবং তৈরি করা যেতে পারে।
পদক্ষেপ:
0.0079375 মিমি
প্যাকেজিং বিবরণ:
শক্ত কাগজ: 36x29x14 সেমি
বিশেষভাবে তুলে ধরা:

NEMA 23 Hollow Shaft Stepper Motor

,

Hollow Shaft Stepper Motor

পণ্য বিবরণ

When encountering sudden load changes, the system can automatically adjust to ensure that the motor continues to work normally.

Through encoder feedback, system debugging and troubleshooting become easier.



Features:

  • We offer tailored services and invite contract manufacturing

  • Our products offer high torque and precision

  • We are looking for dealers!

  • We accept contract manufacturing

  • Our engineers will contact you within 48 hours to offer the most suitable solution





Motor Specifications



Step Angel

1.8 °

Fram Size

57 mm

Number of Phase

2 Phase

Rated Current

2.2 A

Rated Thrust

800N

Resistance

1.6 ohm

Inductance

7.2 mH

Rotor Inertia

260 g-cm²

Motor weight

0.6 kg

Number of leads

2

Connection

Bipolar

Appearance

NEMA 23 Hollow Shaft Stepper Motor 57x57x54mm For Bespoke Ball Screw Or Lead Screw 0

Dimensions

NEMA 23 Hollow Shaft Stepper Motor 57x57x54mm For Bespoke Ball Screw Or Lead Screw 1


Operating Specifications

Step Angle: 1.8°

Maximum  Temperature :80°C maximum

Ambient Temperature: -20 °C to 50°C

Storage Temperature -20: °C to 100°C

Humidity Range (%) :85% or less, non-condensing

Magnet Wire Insulation :Class B 130 deg C

Insulation Resistance :100M Ohm at 500 VDC

Dielectric Strength :500 VDC for 1 min







Torque Curves













Submodels



Model Holding Torque Step Angle Length Type of Shaft Rated Current
57SHD4013-21B 0.6N.m 1.8° 41mm D Shaft-21mm 1.0A
57SHD4415-21B 1.1N.m 1.8° 54mm D Shaft-21mm 3.0A
57SHD4816-21B 2.0N.m 1.8° 76mm D Shaft-21mm 3.0A
57SHD4913-21B 2.5N.m 1.8° 83mm D Shaft-21mm 3.0A
57SHD4934-20B 3.0N.m 1.8° 100mm D Shaft-20mm 3.0A



Download

If our standard motor cannot meet your needs,

we can customize the motor according to your needs


Customized content includes but is not limited to special shafts, winding parameters, installation dimensions, lead wires with special requirements, connectors, etc.

Options:

Encoder

Brake

Gearbox

Shaft
NEMA 23 Hollow Shaft Stepper Motor 57x57x54mm For Bespoke Ball Screw Or Lead Screw 2 NEMA 23 Hollow Shaft Stepper Motor 57x57x54mm For Bespoke Ball Screw Or Lead Screw 3 NEMA 23 Hollow Shaft Stepper Motor 57x57x54mm For Bespoke Ball Screw Or Lead Screw 4 NEMA 23 Hollow Shaft Stepper Motor 57x57x54mm For Bespoke Ball Screw Or Lead Screw 5



Please click the "Get a quote" button below to tell us your requirements.
