1.8 Degree 2 Phase NEMA 34 Waterproof Stepper Motor 76mm Body 5.2N.m

1.8 Degree 2 Phase NEMA 34 Waterproof Stepper Motor 76mm Body 5.2N.m

ব্র্যান্ড নাম:	Casun
মডেল নম্বর:	F86SHD4112-32H
MOQ:	1 পিসি
দাম:	$24.92-$25.96
পেমেন্ট শর্তাবলী:	D/A, T/T, L/C, D/P
সরবরাহ ক্ষমতা:	40000+Pcs+মাস

বিস্তারিত তথ্য

পণ্য বিবরণ

বিস্তারিত তথ্য

উৎপত্তি স্থল:

চীন

সাক্ষ্যদান:

CE,ROSH,ISO

স্টেপ এঞ্জেল:

1.8°

টর্ক ধরে রাখা:

5.2Nm

কারেন্ট:

5.0A

মোটর দৈর্ঘ্য:

76 মিমি

খাদ:

কীওয়ে খাদ 32 মিমি দৈর্ঘ্য

প্যাকেজিং বিবরণ:

শক্ত কাগজ: 36x29x14 সেমি

বিশেষভাবে তুলে ধরা:

76mm NEMA 34 Stepper Motor

Waterproof NEMA 34 Stepper Motor

5.2N.m NEMA 34 Stepper Motor

পণ্য বিবরণ

NEMA 34 is capable of driving heavier loads and is suitable for high-precision and high load motion control.

NEMA 34 stepper motors are widely used in various fields such as 3D printers, CNC machine tools, automation equipment, medical equipment, etc.

Features:

We are a professional research and development manufacturing company
Enjoy a ten-year warranty and purchase with confidenc
We provide tailored services and welcome contract-based production
High torque and precision guaranteed
Expect a response from our engineers within 48 hours with the best solution for your needs

Dimensions

Motor Specifications

Step Angel	1.8 °
Fram Size	86 mm
Number of Phase	2 Phase
Rated Current	5.0 A
Holding Torque	5.2N.m
Resistance	0.75ohm
Inductance	6.4mH
Rotor Inertia	1400 g-cm²
Motor weight	2.3 kg
Number of leads	4
Connection	Bipolar

Operating Specifications

Step Angle: 1.8°

Maximum Temperature :80°C maximum

Ambient Temperature: -20 °C to 50°C

Storage Temperature -20: °C to 100°C

Humidity Range (%) :85% or less, non-condensing

Magnet Wire Insulation :Class B 130 deg C

Insulation Resistance :100M Ohm at 500 VDC

Dielectric Strength :500 VDC for 1 min

Torque Curves

Submodels

Model	Holding Torque	Step Angle	Length	Type of Shaft	Rated Current
86SHD4003-32	4.0N.m	1.8°	69mm	Key Shaft-32mm	4.0A
86SHD4101-32	4.5N.m	1.8°	76mm	Key Shaft-32mm	4.0A
86SHD4201-37	5.6N.m	1.8°	98mm	Key Shaft-37mm	4.0A
86SHD4314-37	6.8N.m	1.8°	112mm	Key Shaft-37mm	5.0A
86SHD4404-37	8.0N.m	1.8°	127mm	Key Shaft-37mm	5.0A
86SHD4505-37	12.0N.m	1.8°	150mm	Key Shaft-37mm	5.5A

Download

If our standard motor cannot meet your needs,

we can customize the motor according to your needs

Customized content includes but is not limited to special shafts, winding parameters, installation dimensions, lead wires with special requirements, connectors, etc.

Options:
Encoder | Brake | Gearbox | Shaft

1.8 Degree 2 Phase NEMA 34 Waterproof Stepper Motor 76mm Body 5.2N.m 1

Please click the "Get a quote" button below to tell us your requirements.
